OptiMill®-3D-BN
The OptiMill-3D-BN ball nose mill cutter has been specifically developed for machining materials up to 55 HRC. It is characterized by high radius accuracy, making it ideal for high-precision machining of 3D contours. In addition to an extremely heat-resistant coating and a special carbide substrate, these tools are distinguished by dimensions and geometries tailored specifically to mold making.
Selected facets:
Remove all filters-
Milling type
-
Product Family
-
Diameter (d1)
-
-
Total length (l1)
-
-
Flute length (l2)
-
-
Neck length (l3)
-
-
Shank type
-
Cooling
-
Product category
(40)
(40)
(40)
(40)-
OptiMill®-3D-BN
l1: 75 mm; l2: 2,9mm; l3: 25 mm; d1: 2,5 mm; d2: 6 mm; R: 1,25 mm; z: 2; MBN101-025-0125-2500X075-HP801
Order number: 31153328
In Stock -
OptiMill®-3D-BN
l1: 50 mm; l2: 2,9 mm; l3: 8 mm; d1: 2,5 mm; d2: 4 mm; R: 1,25 mm; z: 2; MBN101-025-0125-0800X050-HP801
Order number: 31153321
In Stock -
OptiMill®-3D-BN
l1: 50 mm; l2: 2,9 mm; l3: 10 mm; d1: 2,5 mm; d2: 4 mm; R: 1,25 mm; z: 2; MBN101-025-0125-1000X050-HP801
Order number: 31153322
In Stock -
OptiMill®-3D-BN
l1: 50 mm; l2: 2,9 mm; l3: 15 mm; d1: 2,5 mm; d2: 4 mm; R: 1,25 mm; z: 2; MBN101-025-0125-1500X050-HP801
Order number: 31153323
In Stock -
OptiMill®-3D-BN
l1: 60 mm; l2: 2,9 mm; l3: 15 mm; d1: 2,5 mm; d2: 6 mm; R: 1,25 mm; z: 2; MBN101-025-0125-1500X060-HP801
Order number: 31153324
In Stock -
OptiMill®-3D-BN
l1: 50 mm; l2: 2,9 mm; l3: 20 mm; d1: 2,5 mm; d2: 4 mm; R: 1,25 mm; z: 2; MBN101-025-0125-2000X050-HP801
Order number: 31153325
In Stock -
OptiMill®-3D-BN
l1: 60 mm; l2: 2,9 mm; l3: 20 mm; d1: 2,5 mm; d2: 6 mm; R: 1,25 mm; z: 2; MBN101-025-0125-2000X060-HP801
Order number: 31153326
In Stock -
OptiMill®-3D-BN
l1: 75 mm; l2: 9,2 mm; d1: 8 mm; d2: 8 mm; R: 4 mm; z:2; MBN100-080-0400-X075-HP801
Order number: 31354891
In Stock -
OptiMill®-3D-BN
l1: 100 mm; l2: 9,2 mm; l3: 50 mm; d1: 8 mm; d2: 12 mm; R: 4 mm; z:2; MBN102-080-0400-5000D100-HP801
Order number: 31153501
In Stock -
OptiMill®-3D-BN
l1: 100 mm; l2: 9,2mm; l3: 50 mm; d1: 8 mm; d2: 12 mm; R: 4 mm; z: 2; MBN102-080-0400-5000B100-HP801
Order number: 31153499
In Stock -
OptiMill®-3D-BN
l1: 140 mm; l2: 9,2mm; l3: 90 mm; d1: 8 mm; d2: 12 mm; R: 4 mm; z: 2; MBN102-080-0400-9000B140-HP801
Order number: 31153500
In Stock -
OptiMill®-3D-BN
l1: 64 mm; l2: 9,2mm; d1: 8 mm; d2: 8 mm; R: 4 mm; z: 2; MBN100-080-0400-X064-HP801
Order number: 31153244
In Stock -
OptiMill®-3D-BN
l1: 100 mm; l2: 9,2mm; l3: 50 mm; d1: 8 mm; d2: 12 mm; R: 4 mm; z: 4; MBN105-080-0400-5000B100-HP801
Order number: 31153626
In Stock -
OptiMill®-3D-BN
l1: 64 mm; l2: 9,2mm; l3: 25 mm; d1: 8 mm; d2: 8 mm; R: 4 mm; z: 4; MBN104-080-0400-2500X064-HP801
Order number: 31153543
In Stock -
OptiMill®-3D-BN
l1: 100 mm; l2: 9,2mm; l3: 50 mm; d1: 8 mm; d2: 8 mm; R: 4 mm; z: 4; MBN104-080-0400-5000X100-HP801
Order number: 31153544
In Stock
